Mini IT13 | Mini IT12 | Mini IT11 | Mini Air12 | Mini Air11 | A7 | A5 | |
Image | |||||||
Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | Learn More | |
CPU | Core™ i9-13900H Core™ i7-13700H Core™ i5-13500H |
Core™ i7-12650H Core™ i5-12450H |
Core™ i5-1155G7 Core™ i7-11390H |
Intel Alder Lake N100 | Intel® Celeron® Processor N5095 | AMD Ryzen™R9-7940HS AMD Ryzen™R7-7840HS |
AMD Ryzen™ 7 5800H |
GPU | Intel® Iris® Xe graphics compatible | Intel® Iris® Xe | Intel® Iris® Xe | Intel UHD Graphics 12th | Intel® UHD Graphics 605 | AMD Radeon™ 780M Graphics | AMD Radeon™ Vega 8 Graphics |
Memory | Dual-channel DDR4 | Dual-channel DDR4 | Dual-channel DDR4 | Single channel DDR5 | Dual-channel DDR4 | Dual channel DDR5 | Dual-channel DDR4 |
SSD |
1 x M.2 2280 PCIe Gen 4 x4 SSD, support up to 2TB 1 x M.2 2242 SATA SSD slot, expandable up to 1TB 1 x 2.5 SATA HDD (7mm) slot, expandable up to 2TB |
1 x M.2 2280 PCIe Gen 4 x4 SSD, 512GB or 1TB onboard, expandable up to 2TB 1 x M.2 2242 SATA SSD slot, expandable up to 1TB 1 x 2.5 SATA HDD (7mm) slot, expandable up to 2TB |
1 x SSD (2280 M.2 SATA/PCIe),512GB/1TB; expandable up to 2TB 1 x 2.5 SATA HDD (7mm), expandable up to 2TB |
1 x SSD (2280 M.2 SATA & PCIE Gen 3*4), 512G, up to 1TB | 1 x SSD (2280 M.2 PCIe/SATA), 256GB; expandable up to 1TB |
1 x SSD Slot(NVMe Gen4x4 or SATAIII), up to 2TB |
1 x M.2 2280 PCIe Gen 3×4 NVMe/SATA SSD, supports up to 2TB 1 x 2.5” 7mm SATA HDD, supports up to 2TB |
Wifi | Wifi 6E | Wifi 6E | Wifi 6 | Wifi 6 | Wifi 5 | Wifi 6E | Wifi 6 |
Bluetooth | BT 5.2 | BT 5.2 | BT 5.2 | BT 5.2 | BT 4.2 | BT 5.2 | BT 5.2 |
USB Ports | 3 x USB3.2 Gen2 Type A 2 x USB4.0 Type C 1 x USB2.0 Type A |
3 x USB3.2 Gen2 Type A 1 x USB2.0 Type A 2 x USB4.0 Type C |
3 x USB3.2 Gen2 Type A 2 x USB3.2 Gen2 Type C |
3 x USB3.2 Gen2 Type A |
2 x USB 3.2 Gen 1 ports 1 x USB 3.2 Gen 2 port 2 x USB-C ports |
3 x USB3.2 Gen2 Type A 1 x USB2.0 Type A 1 x USB3.2 Gen2 Type C 1 x USB4.0 Type C |
3 x USB3.2 Gen2 Type A |
Multiple Displays | 2 x HDMI2.0 –4K 2 x USB4.0 Type C –8K |
2 x HDMI2.0 –4K 2 x USB4.0 Type C–8K |
1 x HDMI 2.0 –4K 1 x Mini DP 1.4 –8K 2 x USB3.2 Gen2 Type C –8k |
1 x HDMI 2.0 –4K 1 x Mini DP 1.4 –8K |
Two 4K displays | 2 x HDMI2.0 –4K 1 x USB3.2 Gen2 Type C–8K 1 x USB4.0 Type C–8K |
2 x HDMI2.0–4K 2 x USB3.2 Gen2 Type C–8K |
Audio | 3.5 mm headphone jack | 3.5 mm headphone jack | 3.5 mm headphone jack | 3.5 mm headphone jack | 3.5 mm headphone jack | 3.5 mm headphone jack | 3.5 mm headphone jack |
Operating System | Windows 11 Pro | Windows 11 Pro | Windows 11 Pro | Windows 11 Pro | Windows 11 Pro | Windows 11 Pro | Windows 11 Pro |
Size | 117 x 112 x 49.2mm | 117 x 112 x 45.6 mm | 117 x 112 x 45.6 mm | 117 x 112 x 34.2 mm | 117 x 112 x 34.2 mm | 112.4×112.4x 37 mm | 117 x 112 x 49.2 mm |
Weight | 652g | 652 g | 564.9 g | 500.3 g | 500.3 g | 415.5g | 652 g |
